Nora NFRC-R6W3TWMPW 6" Fire Rated Canless Regressed LED Downlight, 1500LM, 5-CCT

The Nora Lighting NFRC-R6W3TWMPW 6" Fire Rated Canless Regressed LED Downlight combines a refined regressed aperture with shallow canless construction and certified fire-rated performance. Delivering a nominal 1500 lumens from only 15 watts, this 6-inch LED downlight provides powerful general illumination without requiring a conventional recessed housing.

Designed for new construction and remodel applications, the NFRC-R6W3TWMPW features five selectable color temperatures from 2700K to 5000K, 90+ CRI, Triac/ELV dimming, IC Airtight construction and wet-location suitability. Its shallow design makes it especially useful for installations with limited plenum space, while the regressed aperture provides a more traditional recessed-light appearance than a flat wafer fixture.

Why Choose the Nora NFRC-R6W3TWMPW?

• 2-Hour Fire Rated: Certified to UL 263 and ASTM E119 for 2-hour fire-rated applications.
• 6" Regressed Design: Provides a deeper, more dimensional recessed-light appearance than a flat wafer-style downlight.
• Canless Installation: No conventional recessed housing is required.
• Shallow Profile: Designed for low-clearance plenums and other space-constrained ceiling applications.
• 1500 Lumens: Delivers powerful general illumination while consuming only 15 watts.
• 5-CCT Selectable: Choose 2700K, 3000K, 3500K, 4000K or 5000K in the field.
• 90+ CRI: Provides high-quality color rendering for natural-looking interiors.
• Dimmable: Compatible with Triac and ELV phase dimming.
• IC Airtight: Designed for appropriate insulated ceiling applications when installed according to Nora's requirements.
• Wet Location Listed: Suitable for applications requiring a wet-location-rated recessed luminaire.
• ENERGY STAR Certified: Energy-efficient integrated LED performance.
• Title 24: Certified to California Title 24 JA8-2025 high-efficacy requirements.
• 5-Year Limited Warranty: Backed by Nora Lighting's limited warranty.

Product Specifications

Regressed Design for a Refined Recessed-Lighting Look

The NFRC-R6W3TWMPW is the regressed version of Nora's 6-inch Fire Rated Canless family. Rather than positioning the luminous surface directly at the ceiling plane, the regressed configuration creates greater visual depth within the aperture.

This makes the fixture a strong choice when you want the installation flexibility of a shallow canless downlight but prefer a more architectural, dimensional recessed-light appearance instead of a completely flat wafer design.

2-Hour Fire Rated Canless Downlight

The NFRC-R6W3TWMPW is designed for projects where fire-rated recessed lighting is required. Nora uses multi-piece construction to provide an additional protective layer above the ceiling, and the fixture is cETLus listed and certified to UL 263 and ASTM E119 for a 2-hour fire rating.

Fire-resistance performance depends on the complete ceiling assembly and proper installation. Always verify the approved ceiling construction, Nora installation instructions and applicable local building and electrical codes for your project.

1500 Lumens from Only 15 Watts

The integrated LED system provides a nominal 1500 lumens while consuming only 15 watts. This provides substantial general illumination from a shallow 6-inch fixture while helping reduce energy consumption compared with traditional light sources.

With 90+ CRI, the fixture delivers high-quality color rendering so furnishings, finishes and interior surfaces appear natural and accurately rendered.

5 Selectable Color Temperatures

A five-position CCT switch located in the junction box allows the installer to choose the preferred color temperature in the field. One fixture can therefore accommodate a wide range of residential and commercial lighting preferences.

• 2700K Warm White: Warm, inviting illumination for bedrooms, living rooms and hospitality spaces.
• 3000K Soft White: A versatile choice for residential interiors, kitchens and hallways.
• 3500K Neutral White: Balanced illumination for residential and commercial environments.
• 4000K Cool White: Crisp light for kitchens, workspaces and commercial interiors.
• 5000K Daylight: Cooler white illumination for applications where bright visual clarity is preferred.

Canless Installation for Shallow Ceilings

No traditional recessed housing is required. The shallow canless construction allows the NFRC-R6W3TWMPW to be installed in low-clearance plenums where a conventional recessed can may be difficult to accommodate.

The fixture includes a pre-wired junction box, while a quick-disconnect connection helps simplify installation. It can be used for remodel projects or new construction, with optional Nora frame-in accessories available when fixture locations need to be established before the finished ceiling is installed.

IC Airtight & Wet Location Rated

The NFRC-R6W3TWMPW is IC Airtight rated for appropriate insulated ceiling applications and is cETLus listed for wet locations. These ratings increase installation flexibility across residential, multifamily, hospitality and commercial projects.

Always follow Nora's current installation instructions and all applicable electrical, building and fire-rating requirements.

Dimmable LED Performance

The NFRC-R6W3TWMPW supports Triac and ELV phase dimming when paired with a compatible dimmer. This allows the same fixture to provide brighter general illumination when needed and softer ambient lighting at lower light levels.

Recommended Applications

• Single-family homes
• Apartments and condominiums
• Multifamily residential projects
• Hotels and hospitality interiors
• Commercial spaces
• New construction projects
• Remodel and renovation projects
• Shallow and limited-plenum ceilings
• Projects requiring fire-rated recessed lighting
• Spaces where a regressed recessed-light appearance is preferred

Compatible Accessories

• NF-R246: Universal New Construction Frame-In for 4" and 6" canless downlights
• NFRC-EW-4: 4' Quick-Connect Extension Cable for Fire Rated Canless Downlights
• NFRC-EW-20: 20' Quick-Connect Extension Cable for Fire Rated Canless Downlights
• NEPK-23LEDUNV: 23W Emergency LED Driver with Remote Test Switch
• NEPK-23LEDUNV-JB: 23W Emergency LED Driver Kit with Remote Test Switch

Accessories are sold separately. Verify current accessory compatibility and all project requirements before ordering.

Frequently Asked Questions

Is the Nora NFRC-R6W3TWMPW fire rated?

Yes. Nora lists the NFRC-R6W3TW as cETLus listed and certified to UL 263 and ASTM E119 for a 2-hour fire rating. The complete ceiling assembly and installation must also meet applicable project and code requirements.

What does regressed mean on a recessed downlight?

A regressed downlight positions the light-producing area deeper inside the aperture rather than directly at the ceiling plane. This creates a more dimensional, traditional recessed-light appearance than a completely flat wafer-style fixture.

How bright is the NFRC-R6W3TWMPW?

Nora rates the 6-inch regressed model at a nominal 1500 lumens while consuming 15 watts, making it well suited for general illumination.

Does the NFRC-R6W3TWMPW require a recessed housing?

No. It is a canless LED downlight and does not require a conventional recessed housing. The fixture includes a pre-wired junction box.

What color temperatures can I select?

Five settings are available: 2700K, 3000K, 3500K, 4000K and 5000K. The CCT can be selected in the field using the switch located in the junction box.

Is the NFRC-R6W3TWMPW dimmable?

Yes. Nora specifies compatibility with Triac and ELV phase dimming. Use a compatible dimmer and follow the manufacturer's installation requirements.

Is this downlight IC rated?

Yes. Nora identifies the NFRC-R6W3TWMPW as IC Airtight rated. Installation must follow Nora's instructions and applicable electrical, building and fire-rating requirements.

Can the NFRC-R6W3TWMPW be used in wet locations?

Yes. Nora lists the fixture for wet locations when properly installed.

Can it be used for both remodel and new construction?

Yes. Nora identifies the fixture for both remodel and new-construction applications. Optional new-construction frame-in accessories are available.

What is the difference between NFRC-R6W1, NFRC-R6W2 and NFRC-R6W3?

All three are 6-inch fire-rated canless LED downlights with selectable CCT. NFRC-R6W1 has a flat aperture and is rated at 1550 nominal lumens. NFRC-R6W2 has a baffled aperture and is rated at 1500 nominal lumens. NFRC-R6W3 has a regressed aperture and is rated at 1500 nominal lumens.
